Introduction
The paper bag handle making machine is specially designed for the production of paper bag carrying handles. It forms handles by sandwiching a flat paper string between two layers of paper, followed by gluing, pressing, and automatic cutting into individual hand pulls.
Paper bag handle making machine is the ideal auxiliary equipment for portable paper bag production lines, providing reliable and reasonable solution for manufacturing flat paper handles used in a wide range of eco-friendly shopping and packaging bags.
Features
1.Use Hot-melt glue not falling
2.Easy to operate, fast.
Main Technical Parameters
Product drawing
|
Name |
paper bag handle making machine |
|
|
Type |
PBH-FP-G |
|
|
Handle Spacing(W) |
78 mm |
96 mm |
|
Paper Board Length(L) |
152 mm |
190 mm |
|
Paper Board Width(h) |
40 mm |
|
|
Rope Diameter(D) |
12 mm |
|
|
Rope Height(H) |
100 mm |
|
|
Max. Speed |
180 pcs/min |
|
|
Paper rope thickness |
25-60 gsm |
|
|
Paper Thickness |
80-150 gsm |
|
|
Max.Roll Diameter |
700 mm |
|
|
Reel inner diameter |
76 mm |
|
|
Air pressure |
≥0.12cmm, 0.4~1Mpa |
|
|
Power |
10KW |
|
|
Weight |
2800 Kg |
|
|
Overall dimension(L×W×H) |
5000×1500×1500 mm |
|
Key Features
√ Integrated Process: Gluing, pressing, and cutting are completed automatically in one smooth operation.
√ High Efficiency: Delivers consistent handle quality at high speed to match bag-making output.
√ Easy Integration: Designed to work as a supporting unit for paper bag machines.
With its efficient design and stable performance, this machine is a crucial addition for manufacturers producing flat-handled paper bags at scale.
Sample
Packaging and Delivery
Why choose US?
1.Our company have multiple guarantees, such as professional technology, high-quality products, attentive service, and outstanding value. Whether it is in terms of production efficiency, product quality, cost control, or long-term cooperation, can provide you with solutions that exceed expectations.
01
2.Our machines can produce a variety of types to choose from, including flat pockets, square bottom paper bags, pointed bottom paper bags, and paper bags with handle, to meet the packaging needs of various industries such as food, clothing, gifts, and building materials.
02
3.Our machinery is designed with a modular structure and is equipped with cost-effective adhesive rollers, blades, and other consumable parts. This design gives us a competitive advantage in sourcing and replacing consumables efficiently.
03
4.Choosing our paper bag machine is not only about choosing efficient production equipment, but also about choosing a partner who can grow together with you. We always take "enhancing customer competitiveness" as our core, using technological innovation and service guarantees to help you seize opportunities in the packaging market.
04
